Low pressure CSD - HSD Series

  • Series: CSD – HSD
  • Motor power: kW
  • Delivery: 8.26 to 86.20 m³/min
  • Discharge pressure: 3.5 bar (g)

The efficient production and treatment of compressed air using a minimum of floor space are requirements that are realized by the 1:1 drive CSD to HSD series machines. They are low power consumers, quiet, require little maintenance and reliably produce high quality compressed air.

  • Save energy with the KAESER SIGMA PROFILE

    At the heart of every screw lies a premium quality airend featuring Kaeser’s SIGMA PROFILE rotors. Operating at low speed, Kaeser’s airends are quipped with flow-optimized rotors for superior efficiency.


    The SIGMA CONTROL 2 ensures efficient control and system monitoring. The large display & RFID reader provide effective communication and maximum security. Multiple interfaces offer exceptional flexibility, whilst the SD card slot makes updates quick and easy.

  • The Future, Today: IE4 Motors

    KAESER is currently the only compressed air systems provider to equip its compressors with Super Premium Efficiency IE4 motors as standard, thereby ensuring maximum performance and energy efficiency.

  • Eletronic Thermo management

    The innovative Electronic Thermo Management (ETM) system dynamically controls fluid temperature to provide reliable prevention of condensate accumulation. This enhances energy efficiency, for example, by enabling heat recovery to be precisely tailored to meet customers’ exact needs.
